Optical Fiber Cable

Get a Price/Quote

Optical Fiber Cable Specification

Diameter
2.0 - 8.0 mm

Rated Temperature
-20C to +70C

Cable Type
Singlemode / Multimode

Insulation
PVC / LSZH

Usage & Applications
High-speed data transmission, long-distance communication, CCTV, uplink/downlink, indoor/outdoor installations

Number of Conductor
1 / 2 / 4 / 6 / 8 / 12 (Customizable core count)

Dielectiric Strength
>3 kV/mm (typical for insulation)

Armored Material
Corrugated Steel Tape / None (optional)

Features
High bandwidth, low signal attenuation, lightweight design, flexible and durable, immune to electromagnetic interference (EMI)

Locking Type
Standard Push-Pull (as per connector)

Operating Temperature
-20C to +70C

Tensile Strength
800 N (Short Term) / 400 N (Long Term)

Impedance
NA (Optical)

Conductor Type
Singlemode or Multimode

Conductor Shape
Round

Install Type
Indoor/Outdoor, Aerial, Duct, Direct Burial

Core Number
1, 2, 4, 6, 8, 12+ (as per design)

Core Material
Glass (Silica-based)

Weight
Approx. 15-80 kg/km (varies with core count)

Product Type
Optical Fiber Cable

Length
Available in custom lengths (10m, 20m, 50m, 100m, etc.)

Voltage
Low Voltage (Data Transmission); typically rated for optical signal, not electrical

Insulation Material
PVC / LSZH (Low Smoke Zero Halogen)

Application
Telecommunication, internet backbone, data centers, FTTH, LAN

Conductor Material
Glass / Plastic (Optical Fiber Core)

Jacket Material
PVC / LSZH

Storage Temperature
-40C to +70C

Connector Color
Blue / Yellow (as per connector type)

Shield Material
Aramid yarn / None (depending on cable type)

Jacket Color
Black / Yellow / Orange

Dimension (L*W*H)
Varies by length and core count, typically 2.0 mm - 8.0 mm

Color
Black, Yellow, Orange

Material
Glass Fiber, PVC, LSZH

Size
2.0 mm to 8.0 mm Diameter

Attenuation
0.35 dB/km (1310nm, Singlemode); 3.5 dB/km (850nm, Multimode)

Connector Type
SC, LC, ST, FC (as per requirement)

Minimum Bending Diameter
20 mm (typical)

Fiber Type
G.652D, OM1, OM2, OM3, OM4

RoHS Compliance
Yes

Water Blocking
Available (gel-filled or dry core)

Flame Retardancy
IEC 60332-1, FRLS (on request)

Outer Sheath Type
UV resistant, Flame retardant (on request)

Bend Radius
10 x Cable Diameter (static); 20 x Cable Diameter (dynamic)

Standards
Complies with ITU-T G.652D, ISO/IEC 11801, RoHS

Crush Resistance
>1000 N/100 mm

Fiber Count
Customizable from 1-288 fibers

Mode Type
Singlemode (OS2), Multimode (OM1/OM2/OM3/OM4)

Optical Fiber Cable Trade Information

Minimum Order Quantity
100 Meter

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Per Month

Delivery Time
10 Days

About Optical Fiber Cable

Experience a radiant upgrade with our Highly Recommended Optical Fiber Cable-available in both Singlemode (OS2) and Multimode (OM1/OM2/OM3/OM4) options for premier performance. This exquisite cable features customizable fiber counts from 1 to 288, a UV-resistant or flame-retardant sheath, and industry-compliant connectors (SC, LC, ST, FC). Offering low attenuation, high bandwidth, and exclusive crush resistance, it's ideal for telecommunication, data centers, and internet backbones. Promotion: Enjoy exceptional durability, flexible installation, and robust water blocking-making it the preferred choice for demanding environments.

Competitive Advantages and Versatile Applications

Our Optical Fiber Cables stand out with premier performance, robust UV-resistant sheathing, and flame-retardant options. Designed for both specific and general applications, they are highly valued in high-speed data transmission, long-distance communication, CCTV, and indoor/outdoor network installations. Their exquisite construction ensures immunity to EMI and supports a wide range of environments-from FTTH to data center operations-making them a highly recommended choice for competitive projects and general infrastructure demands.

Swift Delivery Time & Premium Export Capabilities

Our logistics network ensures prompt delivery across India's main domestic market and supports seamless export logistics to premium markets worldwide. With efficient order processing and timely project fulfillment, we keep your operations ahead of schedule. As a trusted supplier and trader, we're dedicated to superior service and supply for India and key global regions, facilitating the exclusive access of our optical fiber cables to discerning international and domestic customers alike.

FAQ's of Optical Fiber Cable:

Q: How do I select the right connector type for my optical fiber installation?

A: Choosing the right connector (SC, LC, ST, FC) depends on your equipment and installation requirements. Consider compatibility with existing hardware and space constraints-LC is compact for dense setups, while SC and FC provide robust connections for various telecom applications.

Q: What environments can this optical fiber cable be used in?

A: Our cable is engineered for both indoor and outdoor installations, including aerial, duct, and direct burial applications. It's suitable for use in data centers, telecommunication backbones, LAN, CCTV, and FTTH, offering flexibility across diverse environments.

Q: What is the process for requesting custom fiber counts or lengths?

A: To order customized fiber counts (from 1 up to 288 fibers) or specific lengths, simply specify your requirements during inquiry. Our support team will guide you through the manufacturing and logistics process for prompt and accurate fulfillment.

Q: How does water blocking in your cables enhance performance?

A: Water blocking, available as gel-filled or dry core, protects against moisture ingress, ensuring reliable long-term performance and minimizing downtime, especially in demanding or underground environments.

Q: When can I expect delivery for domestic and export orders?

A: Domestic deliveries are handled swiftly using our streamlined logistics, while export deliveries are processed with premium shipping partners. Timelines vary depending on location and order size, but most shipments are dispatched quickly to meet critical project schedules.
